224-310KW广西顶博发电机组制造:康明斯发电用发动机可靠性高：高强度合金铸造缸体、可锻铸铁(FCD) 活塞，刚性更好，降低振动和噪声，提高了发动机适应更高的爆发压力。

High reliability: intensified alloy casting cylinder and Ferrous Cast Ductile (FCD) piston provide engine a better rigidity performance and lower vibration & noise, and also make the engine adapt to higher explosion pressure.

康明斯生产发电用起心理然油经济增长性好: 发达的然油调整系统的的，独具特色的STC、ESTC 等级分类调整系统的的，特出方案的缸筒上端焚烧室，高压低压喷出然油，有效做雾化，焚烧有效。

Good fuel economy: Advanced fuel control system, unique STC, ESTC step control system, specilly-designed piston topchamber and high pressure fuel injection lead to an excellent fuel consumption rate and emission performance of engine.

康明斯电站用发起机瞬态耐热性优良: 好的发起机整个定制，合作康明斯独具特色的EFC模式，把控好的精密性高，积极响应的时间快。

Excellent transient performance: perfect overall engine design with unique Cummins EFC system, high precision on control and quick response time.

康明斯发电厂用打着机升工作效率高: 整体风格的设计紧促.外观形状布置教室合理化，自动运行有序。High lift power: Integrated and compact design, reasonable layout and smooth operation.

电喷型号规格 QSNT. QSK19. QSK38. QSK50实现国内 非城市道路第3价段及南美Tier2. Tier 3排放口标准请求。

Electric fuel injection engines (QSNT,QSK19,QSK38,QSK50) meet the Tier3 emission regulations for China non-road vehicles and Tier2 & Tier3 emission regulations of North America.

零零部件必须性好， 汽车发思想开机运行及服务器维护的保养便捷，成本又低。Good availbility of spare parts, smooth engine operation, convenient engine maintenance and low cost.

发动机规格Engine Specifications

电功率依据 Power Range   224-310KW连接结构 Type   直列/六缸/四冲程/四气门  In-ine/6-Cylinder/4-Stroke/4-Valve缸径x冲程 BoreX Stroke  125X 147mm排量 Displacement   11L外貌尺寸图 Dimension  长X宽X高(LXWX H) 1360 x 833X 1068 mm净服务质量 Dry Weight   940kg

224-310KW康明斯发电厂用汽车发驱动力的的特点：体型小， 减小比低， 隔栅气升温，方便重新启动，移动端汽车导航电源开关的首推。Compact size, high compression ratio, gile heated by air, easy for start-up, the first option of mobile vehicle power supply.

推荐机型Engine Models Recommended

打火机参数	最常见热效率(kW)Prime Power	紧急电率kW)Standby Power
MTA11-G2	224	246
MTAA11-G3	282	310
